| LOCATION: |
| City: |
Apodaca,
Nuevo León (Monterrey) |
| Industrial Park: |
Regio Park
(Regio Parque Industrial) |
| BUILDING
AREA: |
| Total area: |
72,086 sqft |
| Production/warehouse: |
68,523
sqft |
| Office: |
3,562 sqft |
| Expansion: |
72,086 sqft |
| BUILDING
CONFIGURATION: |
| Clear height below frame: |
24 ft |
| Column spacing: |
89' X 31.3' |
| Roof slope: |
8.33% |
| Roof type: |
U.S. Standing Seam |
| Roof Insulation: |
3.5" fiberglass |
| Wall type: |
0'
to roof line, precast concrete |
| Wall insulation: |
Concrete, 2" polystyrene |
| RESTROOM: |
| Men: |
100 persons |
| Women: |
100 persons |
| Office: |
50 persons |
| EXTERIOR
AREAS: |
| Dock spaces: |
3 |
| Access ramp: |
1 |
| Parking spaces: |
27 car |
| ELECTRICAL
/ ILUMINATION: |
| KVA: |
OPTIONAL (main 13,200 Volts) |
| Production/warehouse illum.: |
30 ft candles |
| Office illumination: |
100 ft candles |
| Restroom illumination: |
50 ft candles |
| Exterior illumination: |
yes, wall packs
building |
| A/C: |
| Office: |
yes 1 ton / 220 sqft |
| Production: |
OPTIONAL (Upon request) |
| OTHER: |
| Water storage: |
10,000
lt. |
| Garden sprinkler system: |
yes, Automatic |
| Guard house: |
OPTIONAL (Upon request) |
| |
For a full description of
the building's specifications please go to it's SPECIFICATIONS
PAGE.
If your company has additional equipment and
installations needs we can work with you to include them
as part of the lease. |
|
 |
